Slic3r settings to consider changing to get good plotsįirst, download Inkscape from their website.
How to extrude and export that object as an STL ready for slicing.How to import that SVG image into Fusion 360 as a sketch and use a plug-in to repair any open loops that may result from complex geometry.How to use Inkscape to convert any image type into an SVG (Scalable Vector Graphic) image type.This Instructable will cover the following (represented in images above) Knowing that I would want solid infill for future engravings and such, I found a way to use Fusion 360 to turn the whole image into a 1 layer thick 3D object so that I can slice it and export the gcode just like if I were 3D printing. There are many instructions online to do so, however all of the ones I found used Inkscape with the J Tech Photonics Laser Tool Plug-In to create gcode for tracing just the outline of your object. The overall goal of this Instructable is to take a picture from the internet and convert it into gcode that is usable by your printer. However, my thought is that with this up and running, the methods used can be easily extended to allow for laser engraving, CNC milling, PCB prototyping, and more. For starters, I've added a pen plotter, which is mostly a novelty since anything a pen can draw could also be printed on a traditional computer printer. Since I first built my 3D printer, I've seen the possibilities for modifying and adding to it in order to increase its capabilities.
